Kyocera TASKalfa 4012i

Specification

GENERAL
Technology: KYOCERA TASKalfa, Laser, Monochrome,
HyPAS™ solution platform
Operation panel: 228.6 mm (9 inch) full-colour touch
panel display, speaker for job notification, 15° – 90° swivel
mounted
Type: Desktop
Engine speed: Up to 32 pages A4 per minute
Up to 17 pages A3 per minute
Duplex print speed: 29 page per minute, A4
Duplex copy speed: 29 page per minute, A4
Resolution: 1200 x 1200 dpi (print, at reduced speed),
600 x 600 dpi (scan/copy)
Warm-up time: Approx. 18 seconds or less
Time to first print: Approx. 4.9 seconds or less
Time to first copy: Approx. 5.2 seconds or less (DP),
Approx. 4.3 seconds or less (Platen Cover)
CPU: QorIQ T1024 (Dual Core) 1.0GHz
Memory: Standard 2GB + 32GB SSD, Max. 2GB + 32GB SSD
+ 320GB HDD
Standard interface: USB 2.0 (Hi-Speed), 4 x USB Host
Interface, Gigabit Ethernet (10BaseT/100BaseTX/
1000BaseT, IPv6, IPv4, IPSec, 802.3az support), optional
Wi-Fi (IEEE 802.11b/g/n), 2 eKUIO slots for optional
internal print server, Slot for optional SD Card, NFC tag
Integrated accounting: 1000 department codes
Dimensions (W x D x H): 594 x 696 x 683 mm
Weight: Approx. 59 kg
Power source: AC 220 ~ 240 V, 50/60 Hz
Power consumption
Printing: 510 W
Copying: 510 W
Low power mode: 70W
Ready mode: 100 W
Sleep-mode: 1.0 W
Noise (surface sound pressure level)
Sleep mode: Immeasurably low
Ready mode: Immeasurably low
Printing: 45.8 dB (A) LpA
Safety standards: TÜV/GS, CE
This unit is manufactured according to ISO 9001 quality
standard and ISO 14001 environmental standard.
PAPER HANDLING
All paper capacities quoted are based on paper thickness
of max. 0.11 mm. Please use paper recommended by
KYOCERA under normal environmental conditions.
Input capacity:
100-sheet multi-purpose tray, 45–256 g/m2 A3, A4, A5, A6,
B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x
432 mm), Standard universal paper cassette: 2 x 500 sheet
60–163 g/m2 A3, A4, A5, B5, Ledger, Letter, Legal, Folio.
Max. input capacity with options: 4,100 sheets A4
Duplex unit: Duplex as standard supports 60–163 g/m2
A3 to A5R
Output capacity: Max. 300 sheets, 250 sheets face-down
(Main Tray) plus 50 sheets (standard Job Separator Tray
PRINT FUNCTIONS
Controller language: PRESCRIBE II e
Emulations: PCL6 (5e/XL), KPDL3 (PostScript 3 compatible),
PDF Direct Print, XPS Direct Print and Open XPS, PPML
Operating systems: All current Windows operating systems,
MAC OS X Version 10.5 or higher, Unix, Linux as well as other
operating systems on request
Fonts/barcodes: 93 outline fonts (PCL), 93 fonts (KPDL 3),
8 fonts( Windows Vista), 1 Bitmap font, 45 types of onedimensional
barcodes, 1 type of two-dimensional barcode
(PDF417)
Print features: Encrypted PDF Direct Print, IPP printing,
e-mail printing, WSD print, secure printing via SSL, IPsec,
SNMPv3, quick copy, proof and hold, private print,
job storage and job management functionality
Mobile printing support: KYOCERA Mobile Print app for
iOS and Android, AirPrint, Mopria, NFC, Wi-Fi Direct,
Google cloud print
COPY FUNCTIONS
Max. original size: A3/Ledger
Continuous copying: 1–999
Zoom range: 25–400% in 1% steps
Preset magnification ratios: 5 Reductions / 5 Enlargements
Exposure mode: Auto, manual: 17 steps
Image adjustments: Text + Photo, Photo, Text, Map,
Printed document
Features: Scan-once-copy-many, electronic sort, 2in1, 4in1,
image repeat, page numbering, cover mode. booklet copy,
interrupt copy, form overlay, margin shift, auto cassette
change, Skip blank page, ID copy in Program mode
SCAN FUNCTIONS
Functionality: Scan-to-Email, Scan-to-FTP, Scan-to-SMB,
Scan to USB Host, Network TWAIN , WIA , WSD scan
Scan speed: 80 ipm (300 dpi, A4, b/w, with DP-7110/7100)
80 ipm (300 dpi, A4 colour, with DP-7110/7100)
48 ipm (300 dpi, A4, b/w, with DP-7120)
48 ipm (300 dpi, A4 colour, with DP-7120)
Scan resolution: 600, 400, 300, 200 dpi, 400 x 200,
200 x 100 dpi, 256 greyscales per colour
Max. scan size: A3, Ledger, Banner up to 1900 mm
Original recognition: Text, photo, text + photo, light text,
optimised for OCR
File types: TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted
PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u
Compression method: MMR/JPEG
Features: Colour scan, integrated address book, Active
Directory support, encrypted data transfer, multi send
(e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
FAX FUNCTIONS (OPTIONAL)
Compatibility: ITU-T Super G3
Modem speed: Max. 33.6 kbps
Transmission speed: Max. 3 seconds (JBIG)
Scanning speed: 2.0 seconds or less
Address book: 2000 entries
Scanning density:
Normal: 8 dot/mm x 3.85 line/mm (200 x 100 dpi)
Fine: 8 dot/mm x 7.7 line/mm (200 x 200 dpi)
Superfine: 8 dot/mm x 15.4 line/mm (200 x 400 dpi)
Ultrafine: 16 dot/mm x 15.4 line/mm (400 x 400 dpi)
Halftone: 256 grey scales
Maximum original size: A3, Ledger, Banner up to 1600 mm
Compression method: JBIG, MMR, MR, MH
Memory reception: 7,000 sheets or more
Features: Network fax, duplex transmission and
reception, encrypted transmission and reception, polling
transmission and reception, broadcast, optional internet
fax, dual fax with second fax system 12
CONSUMABLES
Average continuous toner yield in accordance with
6% coverage A4
TK-7125 Toner Kit: Microfine toner black for 20,000
pages A4
SH-10 Staple cartridge: 3 x 5000 staples, for DF-7120
SH-12 Staple cartridge: 3 x 5000 staples, for DF-791
OPTIONS
Fax System: Fax System 12
Internet Fax Kit: Internet Fax Kit (A)
Scan extension Kit (A): Scan to searchable PDF solution
(embedded OCR), convert to PDF or MS Office (docx, xlsx,
pptx)
Paper handling
DP-7100 Document processor: (Reversing), 140 sheets,
35–160 g/m2 (simplex), 50–120 g/m2 (duplex), A6R–A3,
Banner up to 1,900 mm
DP-7110 Document processor: (one-path duplex scanning),
270 sheets at 50–80 g/m2, 35–220 g/m2 (simplex),
50–220 g/m2 (duplex), A6R–A3, Banner up to 1,900 mm
DP-7120 Document processor: (Reversing), 50 sheets,
45–160 g/m2 (simplex), 50–120 g/m2 (duplex), A5R – A3,
Banner up to 1,900 mm
DT-730(B) Document tray
PF-791 Paper feeder: 2 x 500 sheets, 60–256 g/m2, A5R–A3
PF-810 Paper feeder: 3,000 sheets A4, 60–256 g/m2, A4,
B5, Letter
DF-791* Document finisher + AK-740: Main tray: 3,000
sheets A4, sub tray: 200 sheets A4, 60–256 g/m2,
B5R–A3, Stapling up to 65 sheets A4 or 30 sheets A3 at 3
positions, B5–A3. * Bridge unit AK-740 is required when
using a finisher
DF-7120* Document finisher + AK-740: 1,000 sheets A4,
52–300 g/m2, A6R–A3, Stapling up to 50 sheets A4 or 30
sheets A3 at 3 positions. * Bridge unit AK-740 is required
when using a finisher
PH-7C/PH-7D Punch unit for DF-791/DF-7120:
2-hole/4-hole/Swedish type, 60–256 g/m2, A5R–A3
MT-730(B) Mailbox sorter for DF-791:
7 bins x 100 sheets A4, 50 sheets A3/B4, 60–163 g/m2
HD-12 Storage: Optional HDD 320 GB
Data Security Kit (E): In line with ISO 15408
(Common Criteria) with security level EAL2
NK-7100 Numeric keypad
Keyboard Holder 10
UG-33: ThinPrint support
UG-34: Emulation (IBM Proprinter/EPSON LQ-850/
Diablo 630)
USB IC Card Reader + Card Authentication Kit (B):
Support for various authentication keys available.
The card holder is standard
Optional interface
IB-35: Wi-Fi Direct, Wireless LAN Interface (802.11b/g/n)
IB-50: Gigabit-Ethernet board 10 BaseT/100 BaseTX/
1,000 BaseT
IB-51: Wireless LAN Interface (802.11b/g/n)
Platen cover Type (E)
CB-810 Cabinet: Wooden desk with storage capacity,
including castors (wheels)
CB-811 Cabinet: Metal desk with storage capacity,
including castors (wheels)
